Tedder
Machine description:
- The excellent PKM53 tedders are characterised by the use of high-quality materials and working efficiency.
They meet the highest European standards: - ow machine weight,
- low Cardan connection speeds,
- easily accessible lubrication points,
- high tedding efficiency thanks to the carousel system,
- side carousels hydraulically lifted by transport cylinders (double-acting cylinders),
- guard rails,
- 3-position finger angle,
- angled positioning of the machine at the edge of the field (17o),
- torsional suspension system, which makes it easier to operate the machine when turning,
- easy replacement of springs,
- high durability of gearings thanks to the use of carburized gears,
- smooth working disc prevents grass from sticking,
- spring protection against loss (optional).
Technical data:
Didn't find the answer to your question? Please feel free to contact us.
ContactWhich rotary tedder does AGROKOWALSKI offer?
The range includes the four-rotor PKM53 (Z528) rotary tedder with a 5.30 m working width
What tractor horsepower is required for the PKM53?
The minimum tractor power is approximately 40 HP.
How many rotors and arms does the PKM53 have?
The machine has 4 rotors, each equipped with 6 arms.
What PTO speed is required?
The tedder is designed to operate at 540 rpm PTO speed.
How is the machine folded for transport?
The side rotors are hydraulically raised using double-acting cylinders. The transport width is approximately 3.00 m and the transport height approximately 2.80 m.
Can the working angle of the tines be adjusted?
Yes. The design provides three working-angle settings: 12°, 15° and 18°.
Can the tedder operate along the field boundary?
Yes. The machine can be angled at the field edge by approximately 17°, helping to limit material being thrown outside the working area.
Are the springs secured against being lost?
This retention system is available as optional equipment.
